D 20 7
- (F): camera display
- The vehicle positions monitored by camera are shown in the display
- Direct jump to display menu 13 - camera display
- (G): diesel engine speed
- Direct jump to set-up menu 101 - diesel engine speed
Depending on operating status, different symbols are shown at position (10):
Hare: Transportation gear active
Tortoise: Working gear active
STOP: Machine stop
20km/h Important! Machine speed too high! Reduce travel!
Snow flake: hydraulic oil temperature too low! Let machine run up to tem-
perature with stationary acceleration!
A
The engine speed cannot be increased when the hydraulic oil temperature
is too low!
Hare with wheels: Trailer (o) connected.
A
When the trailer (o) is connected, all screed, auger and levelling functions
are locked, apart from lifting/lowering screed.
