D 13 51
Item Designation Brief description
83
Battery charge in-
dicator (red)
Must go out after starting when the engine revs up.
- If the light does not go out, switch off the engine
84 not used
85
Error message
(yellow)
Indicates that there is a drive engine fault. Depending on the
type of fault, the vehicle can temporarily continue to be operat-
ed or, in the case of serious faults, should be shut down imme-
diately to prevent further damage from occurring.
Each fault should be rectified as soon as possible!
A
The error code can be called up using the switch
"Call up error / malfunction".
A
Lights up for a few seconds once the ignition has been
switched on for checking purposes.
86
Oil pressure indica-
tor lamp for the die-
sel engine (red)
m
Lights up when the oil pressure is too low.
Switch off the engine immediately!
For further possible faults, see Engine operating in-
structions.
A
Indicates the fault together with the "Error message"
lamp.
87
Oil pressure indica-
tor for the hydraulic
travel drive (red)
Must go out right after the engine has been started. Observe
warm running. The hydraulic oil is possibly too cold and stiff.
m
Do not switch on the travel drive when the lamp does
not go out (see the section "Malfunctions").
A
The lamp goes out when the pressure drops below
2.8 bar = 40 psi.
88
Differential lock in-
dicator (yellow)
Lights up when the differential lock is switched on.
A
The differential lock is automatically activated in work-
ing gear.
89
Parking brake
check (red)
Lights up when the parking brake is activated.
