D 20 46

Example:

Explanation:

Warning light and display signal a serious fault on the drive engine with automatic or

necessary engine shut-down.

Display:

SPN: 157

FMI: 3

OC: 1

Cause: Cable break on sensor for rail pressure.

Effect: Engine shut-down.

Frequency: Fault occurs for the 1st time.

Notify customer service of the error number displayed on your paver finisher; the cus-

tomer service department will then discuss the further procedure with you.

STOP
