D 13 9
Item Designation Brief description
15
Travel drive prese-
lector
For setting the maximum speed that can be reached when the
drive lever is at its stop.
A
The scale roughly matches the speed in m/min (during
paving).
f
The vehicle speed cannot be reduced to "0" with the
preselector. The machine advances slightly with de-
flected drive lever, even if the travel drive preselector is
set to "zero"!
16 Steering wheel
The steering wheel movement is transferred hydraulically to
the front wheels.
f
Take the special steering ratio into consideration when
transporting the machine through tight curves
(approx. 3 turns for a full steering lock). Danger of ac-
cidents!
17 Horn
Press in the case of emergencies and to indicate when the ve-
hicle starts to move!
A
The horn can also be used to communicate acoustically
with the truck driver for material loading!
