SOI 02.10 FV 12/142 599 70 59-01
2.3.2.2 - REMOVING THE PROGRAMMER
The electronic programmer can be accessed once the glass front panel has been removed.
To remove the programmer, just pry open the fixing tabs with a screwdriver and extract the
programmer from the front side (see Fig. 14).
Fig. 14
1 - CONTROL PANEL
SUPPORT
2 - FIXING TAB
3 - ELECTRONIC
PROGRAMMER
4 - PHILIPS
SCREWDRIVER
2.3.2.3 - REMOVING THE INDICATOR LIGHTS
To remove the indicator lights, after removing the upper panel, slide them out from the internal part
of the oven (see Fig. 15).
Fig. 15
1 - INDICATOR LIGHT
2 - CONTROL PANEL
SUPPORT
3 - ELECTRONIC
PROGRAMMER
