SOI 02.10 FV 88/142 599 70 59-01
2.11.2 - POSITION OF HINGE FIXING SCREWS
Fig. 181
1 - UPPER HINGE
FIXING SCREWS
2 - HINGE SUPPORT
3 - LOWER HINGE
FIXING SCREWS
2.11.3 - REMOVING THE FRONT PANEL SCREW
Fig. 182
1 - FRONT PANEL
FIXING SCREW
2 - FRONT PANEL ASSEMBLY
2.11.4 - VIEW OF THE HINGE FIXING SCREWS
Fig. 183
1 - UPPER HINGE
2 - UPPER
FIXING SCREW
3 - LOWER
FIXING SCREW
