Electrolux Built-in ovens Service Manual

SOI 02.10 FV 92/142 599 70 59-01
Once you have removed the internal door glass pane (or panes), unfasten the lower right end piece
fixing screw (see Fig. 190).
Fig. 190
1 - LOWER END PIECE
RIGHT SIDE
2 - SUPPORT UPRIGHT
FOR INTERNAL GLASS
3 - INTERNAL FIXING
SCREW
IMPORTANT: As from production week 39 of 2007 (serial no. 739XXXXX) to remove the lower left
end piece, you no longer need to remove the external screw, just unscrew the new screw fitted in
the internal part as for the lower right end piece indicated in Fig. 190.
2.11.11 - EXTRACTING THE LOWER END PIECES
Extract the lower end pieces with force, once you have removed the internal glass and the end
piece fixing screws (see Fig. 191).
Fig. 191
1 - LOWER END PIECE
LEFT SIDE
2 - LOWER END PIECE
RIGHT SIDE
