Electrolux Built-in ovens Service Manual

SOI 02.10 FV 133/142 599 70 59-01
3.8 - ACCESSING THE CONVECTION FAN
To remove the convection fan with snap-on joint:
1 - Remove the tank + steam generator assembly as illustrated in chapter 3.1.
2 - Push the motor anchor tab using a screwdriver (see Fig. 275).
3 - Turn the motor clockwise and extract it (see Fig. 276 and 277)
Fig. 275
1 - CONVECTION FAN MOTOR
2 - MOTOR SUPPORT
BRACKET POSITIONED
AT THE REAR
OF THE OVEN
3 - PHILIPS SCREWDRIVER
4 - ANCHOR TAB
Fig. 276
1 - MOTOR SUPPORT
BRACKET POSITIONED
AT THE REAR OF THE OVEN
2 - CONVECTION FAN MOTOR
