Electrolux Built-in ovens - Removing the All Glass Pyro Oven Door Handle

SOI 02.10 FV 71/142 599 70 59-01
IMPORTANT: Before repositioning the door internal glazing in the correct sequence, make sure
that the side glazing retainer buffers are positioned correctly (see Fig. 138).
Fig. 138
1 - SIDE GLAZING
RETAINER BUFFERS
2 - RIGHT DOOR UPRIGHT
3 - EXTERNAL GLASS
PANE
2.8.3 - REMOVING THE "ALL GLASS" PYRO OVEN DOOR HANDLE
Once you have removed the internal glazing as explained in the previous chapters:
1 - Remove the two screws on the inside of the door (see Fig. 139 and 140).
Fig. 139
1 - DOOR HINGES
2 - INTERNAL GLASS
SIDE RETAINER
BUFFERS
3 - FIXING SCREWS
FOR HANDLE
Fig. 140
1 - RIGHT DOOR
UPRIGHT
2 - INTERNAL GLASS
SIDE RETAINER
BUFFER
3 - TORX
SCREWDRIVER
4 - FIXING SCREW -
FOR HANDLE
