Electrolux Built-in ovens - Removing the Convection Fan Motor with Screws; Snap-On Joint

SOI 02.10 FV 32/142 599 70 59-01
2.4.8 - REMOVING THE CONVECTION FAN MOTOR WITH SCREWS
To remove the convection fan motor:
1 - Remove the convection fan from inside the oven (see Fig. 67).
2 - Detach the connection wires, marking their position.
3 - Remove the three fixing screws securing the fan in place (Fig. 60 Pos. 7).
2.4.9 - REMOVING THE CONVECTION FAN MOTOR WITH SNAP-ON JOINT
To remove the convection fan with snap-on joint:
1 - Push the motor anchor tab using a screwdriver (see Fig. 61).
2 - Turn the motor clockwise and extract it (see Fig. 62 and 63)
Fig. 61
1 - CONVECTION FAN MOTOR
2 - MOTOR SUPPORT
BRACKET POSITIONED AT
THE REAR OF THE OVEN
3 - PHILIPS SCREWDRIVER
4 - ANCHOR TAB
Fig. 62
1 - MOTOR SUPPORT
BRACKET POSITIONED
AT THE REAR OF THE OVEN
2 - CONVECTION FAN
MOTOR
