SmartROC T35/T40 17 Compressed Air System

106 No: 7026962571.1.7027002891 en-US

Paroil Sxtreme Drainage ** Drainage Drainage *

* When changing to the same oil within the interval between changes, drainage is sufficient

** Changing not recommended

17.11 Flushing Air Compressor

WARNING

Risk of Fire and Explosion

Using incorrect or old oil may lead to a risk of fire or explosion in the compressor sys-

tem

u Use correct, new oil according to the Fluids and Lubricating Greases manual.

Precondition

Run the compressor to operating temperature and confirm that the pressure is zero.

Place vessels under the drain plugs.
