SmartROC T35/T40 20 Automatic Central Lubrication System CLS

127 No: 7026962571.1.7027002891 en-US

20 Automatic Central Lubrication

System CLS

20.1 Automatic Central Lubrication System (CLS)

The CLS is auxiliary equipment that lubricates all joints on the complete machine.

A Pump element

B Safety valve

C Plug (timer for pause and running time)

D Filler nipple

E Reservoir

20.2 Pause Time and Running Time Settings

Integrated in the lubrication pump is a timer which controls pause and running times. To

access the timer, remove the plug on the lubrication pump.
