SmartROC T35/T40 22 Service Tool Bag RCS
151 No: 7026962571.1.7027002891 en-US
Pin Function
2 + 15-V DC power supply out
3 Signal in
4 Not Used
5 Not Used
Table22: Pin Configuration for Input X12
1.
Connect the resolver module connector X11 or X12 to test box connector (B).
2.
Connect the multimeter to test box pins 2 and 3.
3.
Set the multimeter to DC voltage.
It must read 4.5 V on connector X11 and 15 V on connector X12.
If the multimeter reading is 0 V, there could be a fault in the signal cable or resolver
module. Continue as follows:
a.
Connect the cable (C) on the test box to resolver module input X11 or X12 and
measure 1 and 2.
b.
Recheck the multimeter reading.
If it is 0 V, there is a fault on the resolver module input, X11 or X12.
22.13 Replacing RCS Module
!
NOTE: Avoid starting the engine/motor while the program is being loaded.
!
NOTE: Do not turn off the system while the program is being loaded.
Precondition
p
The electric power is present at the machine or that the engine/motor is running before
loading the program.
1.
Make sure that the module has the correct address plug and that the end plug (if any)
is put in place.
2.
Read the program into the system again when any of the application modules, I/O, or
resolver module is replaced.
3.
Insert the USB memory stick with the program into the USB port.
4.
Start the RCS.
5.
Follow the instructions on the display.
è
Remove card and restart the system! appears on the display when the pro-
gram is fully loaded.
6.
Switch off the RCS.
7.
Remove the USB memory stick.
8.
Start the RCS.
