SmartROC T35/T40 9 Feed Unit
46 No: 7026962571.1.7027002891 en-US
9.13 Replacing Haul Wire Rope
1.
Operate the drill to about half its length of travel.
2.
Slacken the tension on the wire ropes, bolt (A), and nut (B).
3.
Remove the haul wire rope from its front attachment on the rock drill cradle.
4.
Remove the scraper plate (C) from the intermediate drill rod support.
5.
Loosen the intermediate drill rod support holder (E) so that the intermediate drill rod
support can be lifted.
6.
Remove the wire rope from the wire rope tensioner (D) in the rear part of the beam.
!
NOTE: Make sure that the new wire rope is installed in the same
hole as the old one.
