Epiroc SmartROC T40 Maintenance

SmartROC T35/T40 18 Track Frames
117 No: 7026962571.1.7027002891 en-US
18.3.8 Check Track Chain Elongation for Wear
n
Check chain wear by measuring the distance (A) between the center point in the first
pin to the center point of the fifth pin.
Specification Metric Data Imperial U.S Data
New Track Roller 640 mm 25.19 in
Wear 25% 640.5 mm 25.21 in
Wear 50% 641 mm 25.23 in
Wear 75% 641.5 mm 25.25 in
Wear 100% 642 mm 25.27 in
Also see about this
2 Procedures for Checking Wear [}113]
18.4 Check Track Frames
n
Check for signs of leakage on the traction motor (A).
n
Check for signs of leakage on the traction gears (B).
n
Check for signs of leakage on the carrier roller (C).
n
Check for signs of leakage on the track rollers (D).
