SmartROC T35/T40 21 Winch

133 No: 7026962571.1.7027002891 en-US

21.3 Check Winch Unit Attachment

n

Check the tightening torque on attachment bolts (A).

Number of Bolts Tightening Torque Value

8 350 Nm (258 lbf.ft)
