SmartROC T35/T40 21 Winch
132 No: 7026962571.1.7027002891 en-US
A Cable
B Rope lock
C Connector sleeve with wedge plug
D Hook
Correct assembly:
• The cable must run in line with the eye on the connector sleeve.
• The rope lock must only lock the end cable.
• The free end must be at least 6-9 times the diameter of the cable in order to ensure
that the whole section of the cable that is either lashed-in or annealed and tapered is
outside the connector sleeve.
The cable and winch eye must be checked:
• before each use.
• when replacing the cable.
• when attaching the cable after shortening.
Check that the winch locking mechanism is fully engaged in the drum before use, following
the attachment of the cable eye on the anchorage point.
