SmartROC T35/T40 11 Dust Collector

55 No: 7026962571.1.7027002891 en-US

11 Dust Collector

11.1 Check Dust Collector

Check the suction hoses (A) for damage.

Check the dust gasket (B) for damage and sealing around the pipe.

Check the inlet connector piece (C) for wear.

Check the center hose (D) for its intactness and the sealing.

Check the wear protectors (E) for wear and attachment.
