Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Troubleshooting procedure 156
Confidential
Feed defect 1
Double Feeding
Clean the rollers of the LD Frame Assy and the ADF Pad Assy. If the symptom continues to occur after cleaning, replace the following
parts.
 LD Frame Assy (p. 318)
 ADF Pad Assy (p. 318)
* If the symptom continues to occur after replacing them, replace the
ADF/SCN Unit (p. 309).
(If the symptom continues to occur after replacing the ADF/SCN Unit,
contact the EPSON Service Department.)
Feed defect 2
Document bending
Check that there is no foreign object or damage in the ADF feed path. If a part is found to be damaged, etc. after cleaning the path, replace the
corresponding part or ADF/SCN Unit (p. 309).
(If the symptom continues to occur after replacing the ADF/SCN Unit,
contact the EPSON Service Department.)
Feed defect 3
Paper jam occurs when feeding from the ADF
 Check that the ADF is closed properly.
 Check that the height of the ADF is appropriate.
 Clean the ADF feed path.
 Clean the roller surface of the LD Frame Assy and the ADF Pad
Assy.
Replace the ADF/SCN Unit (p. 309).
(If the symptom continues to occur after replacing the ADF/SCN Unit,
contact the EPSON Service Department.)
Symptom Check and measure Correspondence after confirmation

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
