EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 166
Confidential
Ability bit table of DIS (DTC)
To refer to the bit allocation table and data, rearrange the following high order bits for every 2 bytes of data.
Example of DIS  8020C28AC480D5838018  FCS=80  FIF=20 C2 8A C4 80 D5 83 80 18
hex 2 0 C 2 8 A
bin
0 0 1 0 0 0 0 0 1 1 0 0 0 0 1 0 1 0 0 1 1 0 1 0
bit no.
8 7 6 5 4 3 2 1 16 15 14 13 12 11 10 9 24 23 22 21 20 19 18 17
bit no. DIS/DTC data Content
1 1 Accumulation exchange Internet facsimile simple mode (TTC standard JT-T37) 0
2 On hold 0
3 Real time Internet facsimile (TTC standard JT-T38) 0
4 Third generation mobile communication network 0
5 On hold 0
6 ITU-T Recommendation V.8 ability 1 Function enabled
7 Frame size 0=256 Octet priority 1=64 Octet priority 0 ECM frame size=256
8 On Hold 0
2 9 Transfer of facsimile document 0 No standard for polling transmission
10 Receive fax operation 1 Ability
11 Data Signal Speed 0000=2.4kbps V.27terFB 0010=Unused 0001=Unused 0011=Unused
0100=V.27ter 0100=On hold 0101=On hold 0111=On hold
1000=V.29 1010=Unused 1001=Unused 1001=Unused
1100=V.27ter,V29 1110=Unused 1101=V.27ter,V29,V17 1111=On hold
0 V.27terFB
*When the V8 mode (S-G3) starts, this
bit becomes invalid (0000).
12 0
13 0
14 0
15 Line density (delicate FINE) R8 x 7.7 l/mm or 200 x 200 dpi 1 Ability
16 Encoding method (MR) 0 Ability
3 17 Recording width ability 00=A4 10=A4/B4
01=A4/B4/A3 11=Invalid
0 A4/B4/A3
18 0
19 Ability to record length 00=A4(297mm) 10=A4(297mm) and B4(364mm)
01=No limit 11=Invalid
0 No limit
20 1
21 The receiver's minimum scanning time capability 000=20/20ms 100=5/5ms 101=40/20ms
001=40/40ms 011=10/5ms 111=0/0ms
010=10/10ms 110=2-/10,s
1 20/20ms
22 1
23 1
24 Extended field 1 Extension
