EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 167
Confidential
Example of DIS 8020C28AC480D5838018 FCS=80 FIF=20 C2 8A C4 80 D5 83 80 18
hex C 4 8 0 D 5
bin
1 1 0 0 0 1 0 0 1 0 0 0 0 0 1 0 1 1 0 1 0 1 0 1
bit no.
32 31 30 29 28 27 26 25 40 39 38 37 36 35 34 33 48 47 46 45 44 43 42 41
bit no. DIS/DTC data Content
4 25 On hold 0
26 Uncompressed mode 0
27 Error correction mode (ECM) 1 Ability
28 Set to 0 0
29 On hold 0
30 On hold 0
31 Encoding method (MMR T.6) 1 Ability
32 Extended field 1 Extended
5 33 Invalid field signal capability 0
34 Multiple Polling Capability (DIS) Multiple polling instructions (DIC) 0
35 Polling sub-address capability (DIS) PSA Polling sub -address transmission (DTC) 0
36 Encoding method (T.43) 0
37 Plain interleave 0
38 32 k ADPCM speech coding (TTC JT-G726) 0
39 Hold for using the extended audio encoded. 0
40 Extended field 1 Extended
6 41 Line density (high delicate / S-FINE) R8 x 15.4 l/mm 1 Ability
42 Line density(300) 300 x 300 dpi 0
43 Line density (Ultrahigh delicate / E-FINE) R16 x 15.4 l/mm or 400 x 400 dpi 1 Ability
44 Inch system resolution selection 0
45 Milli-system resolution selection 1 Milli-system resolution selection
46 Minimum scan line time capability at high linear density 0:T15.4=T7.7 1:T15.4=1/2 T7.7 0
47 Selected professional ability (DIS) Select polling sending (DTC) 1 Ability
48 Extended field 1 Extended
