Troubleshooting Fax Troubleshooting 168
Confidential
 Example of DIS 8020C28AC480D5838018 FCS=80 FIF=20 C2 8A C4 80 D5 83 80 18
hex 8 3 8 0 1 8
bin
1 0 0 0 0 0 1 1 1 0 0 0 0 0 0 0 0 0 0 1 1 0 0 1
bit no.
56 55 54 53 52 51 50 49 64 63 62 61 60 59 58 57 72 71 70 69 68 67 66 65
bit no. DIS/DTC data Content
7 49 Sub-address Ability 1 Ability
50 Password / sending identification ability (DIS) Password sending (DTC) 1 Ability
51 Preparation for data file transfer (polling) 0
52 On hold 0
53 Binary file transfer (BFT) 0
54 Document transfer mode (DTM) 0
55 EDIFACT transfer mode (EDI) 0
56 Extended field 1 Extended
8 57 Basic transfer mode (DTM) 0
58 On hold 0
59 Preparation for transferring (polling) documents in character / mixed mode 0
60 Character mode 0
61 On hold 0
62 mixed mode 0
63 On hold 0
64 Extended field 1 Extended
9 65 Processable Mode 26 0
66 Digital network capability 0
67 Full duplex /half duplex capability 0:Half duplex control 1: Half duplex/full duplex control 0
68 Encoder mode (JPEG) 1 Ability
69 Full color mode 1 Ability
70 Set to 0 0
71 12 bit pixel / element 0
72 Extended field 1 Extended
