Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 172
Confidential
 Example of DCS 830042F844 FCS=83 FIF=00 42 F8 44
hex
bin 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
bit no.
56 55 54 53 52 51 50 49 64 63 62 61 60 59 58 57 72 71 70 69 68 67 66 65
bit no. DIS/DTC data Content
7 49 Send Sub-address
50 Sending function identification sending
51 Set to 0
52 On hold
53 Binary file transfer (BFT)
54 Document transfer mode (DTM)
55 EDIFACT transfer mode (EDI)
56 Extended field
8 57 Basic transfer mode (DTM)
58 On hold
59 Set to 0
60 Character mode
61 On hold
62 mixed mode
63 On hold
64 Extended field
9 65 Processable Mode 26
66 Digital network capability
67 Full duplex / half duplex capability 0:half duplex control 1:full duplex control
68 Encoder mode (JPEG)
69 Full color mode
70 Huffman code table for preferential use
71 12 bit pixel / element
72 Extended field
