Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 171
Confidential
 Example of DCS 830042F844 FCS=83 FIF=00 42 F8 44
hex 4 4
bin 0 1 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
bit no.
32 31 30 29 28 27 26 25 40 39 38 37 36 35 34 33 48 47 46 45 44 43 42 41
bit no. DIS/DTC data Content
4 25 On hold 0
26 Uncompressed mode 0
27 Error correction mode (ECM) 1 ECM
28 Frame size 0= 256 oct 1=-64 oct 0 Frame size 256 oct
29 On hold 0
30 On hold 0
31 Encoding method (MMR T.6) 1 MMR
32 Extended field 0 Non Extended
5 33 Invalid field signal capability
34 Set to 0
35 Set to 0
36 Encoding method (T.43)
37 Plain interleave
38 32 k ADPCM audio coding (TTC JT-G726)
39 Hold for using the extended audio encoded
40 Extended field
6 41 Line density (high delicate / S-FINE) R8 x 15.4 l/mm
42 Line density(300) 300 x 300 dpi
43 Line density (Ultrahigh delicate / E-FINE) R16 x 15.4 l/mm or 400 x 400 dpi
44 Select resolution type 0: inch system resolution 1:milimater resolution
45 unused
46 unused
47 Set to 0
48 Extended field

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
