EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 176
Confidential
03239 <- PIX FF
[33,600 bps(V.34) / MMR / A4 / 8x7.7 / 960(E:1)]
Received the 1st page of image signal.
Communication status is described within [ ].
Communication speed (Protocol) :33.6kbps (V.34)
Encoding method : MMR
Paper width : A4
Resolution : 8x7.7 (Fine)
Number of line (number of error line) : 960(E:1)
⇒ An error occurs after receiving the 960th line.
06612 <- DCN FB The communication became impossible due to the error. It ended in failure by
receiving a disconnect command from the sender.
PROTOCL V.34 Displays the protocol set when starting communication (V.34/V.17/V.29)
SPEED 33.600Bps (3429) Displays the speed of the last communication.
Symbol rates are shown in ()
CODING MMR Displays the encoding method set when starting communication (MMR/MR/MH)
Table 4-4. Commands/responses log_ Sample Example (Type = Sending)
Time
(10ms)
Direction
Commands/
responses name
Data Description

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
