EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Service support mode Service Support Mode 217
Confidential
FOR WF-C5210/WF-C5290/WF-C5290A
1. Press and hold down the power button while pressing the [OK] button from
the power-off state until a message appears on the panel LCD.
Figure 5-4. Printer Startup
Figure 5-5. ID number input screen(1)
2. Enter ID number of Service Support Mode, and start the service support
mode.
Figure 5-6. ID number input screen(2)
ID number input procedure
1. Press a number input button ([
] button or [] button) to enter a
number from 1 to 9.
2. Press the input digit shift button ([
] button) to shift to the next digit.
3. Repeat the above procedure to enter the specified ID number.
4. When all of the ID number is entered, press the execute button ([#]
button). A confirmation message appears.
5. Press the execute button ([OK] button) to execute or press the input
digit shift button ([
] button) to enter the number again.
UP/DOWN: [UP][DOWN]
SHIFT: [RIGHT] / Fin: [OK]
_
Enter “61544” when starting service support mode.
Operating procedure
• Number input (move in ascending order): [
] button
• Number input (move in descending order): [
] button
• Input digit shift: [
] button
• Execute: [OK] button
It is not possible to return to the previous digit after
shifting digits. If you wish to correct the number of the
previous digit, proceed with the steps until after Step 4.
and then perform input again.
Please note that the execute button is not enabled until at
least two digits have been entered.
UP/DOWN: [UP][DOWN]
SHIFT: [RIGHT] / Fin: [OK]
****_
To Next Page
