EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 240
Confidential
DISASSEMBLY FLOWCHART
Housing Right
(→P. 242)
A1
D1
B1
E1
C1
Housing Upper
(→P. 243)
ASF Front Cover
(→P. 241)
Housing Left
(→P. 243)
Ink Eject Cover
(→P. 242)
Start
Housing Left
(→P. 243)
B2
D5
D2 E2
C2
D3 E3
C3
D4 E4
E5
Cover Open Sensor
(→P. 244)
E6
