Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Adjustment Adjustment and Inspection Overview 556
Confidential
Maintenance
Head Cleaning
Run this cleaning when dots missing
is observed on an adjustment pattern
printed by the adjustment program.
Paper type: Plain paper
Size: A4
Paper source: Paper cassette (1)
Perform a head cleaning using the adjustment program, and
print a nozzle check pattern to see if all the nozzles fire ink
properly.
 Adjustment
Program
-
Ink Eject
Discharges the ink inside the ink
supply path when removing the
printhead and ink supply path.
-
Select “Ink Eject” from the Adjustment Program menu and
execute it.
 Adjustment
Program
-
Ink Charge
Fill the print head and ink channels
with ink to enable printing.
-
Select “Ink Charge” from the Adjustment Program menu and
execute it.
 Adjustment
Program
-
Temperature and
Humidity Sensor Check
Check that the temperature and
humidity sensors are operating
normally.
-
Select Temperature and Humidity Sensor Check" from the
Adjustment Program and execute the item, and then determine
whether or not the sensor operation is normal or abnormal
based on the displayed temperature and humidity information.
 Adjustment
Program
-
Touch Panel
confirmation
Check that optical touch panel LED
levels are within standards.
-
Select “Touch Panel confirmation” from the Adjustment
Program menu and execute it.
 Adjustment
Program
-
CR Unlock Unlock the CR Unit. -
Select “CR Unlock” from the Adjustment Program menu and
execute it.
 Adjustment
Program
-
Preparation for
shipment
After repairs, reset the error history,
and as necessary select cleaning
when the printer is next turned on.
-
Select “Preparation for shipment” from the Adjustment
Program menu and execute it.
 Adjustment
Program
-
Final check pattern print
Use this to check if the all
adjustments have been properly
made.
Paper type: Plain paper, Photo
matte paper
Size:A4
Paper source: Paper cassette (1)
Rear ASF Assy
Select “Final check pattern print” from the Adjustment
Program menu and execute it.
 Adjustment
Program
-
Adjustment name Purpose
Adjustment /
inspection paper /feed tray
Adjustment procedure overview Tools
Reference

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
