System 5 Digital Audio Mixing System Operation Manual Channels and Strips
121
8.4.3 Equalizers and Filters
Each channel has a four-band, parametric equalizer and two filters. Press the EQ func-
tion switch to display the EQ controls on the knobset. Press the
key or the * key to
Filters page (Figure 8-16).
Figure 8-16 EQ and Filters knobsets
Page keys display
Filters or EQ pages
Listen
HiQ
HmQ
LmQ
LoQ
HiF
HiG
HmF
HmG
LmF
LmG
LoF
LoG
F2tp
F2Q
F2fr
F1tp
F1Q
F1fr
High band In/Out
High-mid band In/Out
Low-mid band In
/Out
Low band In/Out
Filter 2In
/Out
Listen
Filter 1In
/Out
display the
