System 5 Digital Audio Mixing System Operation Manual Control Groups and Multi Format Masters
137
Figure 10-1 Groups Panel
10.1.1 Create Control Group
1. Press the New key at the bottom-left of the Groups Panel (Figure 10-1).
2. Select the slave channels by pressing their Chan Select keys.
The Chan Select keys flash to show they are included in the Control Group.
Press the Chan Select key again to remove it from the Control Group. The
Slave LED lights.
3. Press a Control Group key in the Groups Panel.
The Name key flashes to show the Control Group is ready to be named from
the keyboard (four characters maximum).
Other Groups can be included as slaves but a slave from another Control Group cannot
be included in the new Control Group.
Main
Panel
Info
Groups
Strg
Vox
G5
Coal
Drms
Guit
G6
G7
G8
G9
G10
G11
G12
New Mod Clr Name
Create New
Group
Clear
Group
Modify
Group
Rename
Group
Coalesce
Group
Page
G14
G15
G16
G17
G18
G19
G20
G13
G22
G23
G24
G21
â—„ â–º
