System 5 Digital Audio Mixing System Operation Manual GPI/O Event System
165
13.2 Output Types
Table 13-2 GP Output Types, Settings, and Activation Values
Output Type Settings Activation Values
Control Room
Monitor A
Monitor B
Monitor C
Monitor D
Control Room Cut
Control Room Dim
On
Off
GP Output
Relay Output #: (1-32)
Pulse length ms (0 to latch): 0 to -1000 ms
Machine: GP132 One
GP132 Two
GP132 Three
GP132 Four
GP132 Five
Open
Closed
Switch Output
Channel #
Channel
EQ
Filters
Dynamics
On
Off
Transport Ctrl
Play
Stop
Fast Forward
Rewind
Scene
Take
Finish
Next
Prev
GoTo
Recall
Layout Recall
Layout #
Meter Preset Recall
Meter Preset #
Snapshot Recall Snapshot #
Mon A
Mon B
Mon C
Mon D
All Mons
Aux Bus
Talkback Control
On
Of
