System 5 Digital Audio Mixing System Operation Manual Quickstart to Common Tasks
30
Assign Channel to Console
1. Select Channels from the Main Panel Viewer.
2. Select Auto then Channel 3.
3. Press the Chan Sel key on a Strip.
4. Press the Inpt button on the strip, then turn the Inpt knob clockwise until the
B input is selected.
5. Press the button to display the B input page on the knobset.
Back to PatchNet
1. In PatchNet, select Console I/O.
2. Select the B Input of Channel 3.
3. Select Sources. .
4. Select Mic-Line 1, Ch 1, and name the channel.
5. Click Patch.
The knobs on Channel 3 now display HiZ, 48V, HPF, Gain.
Figure 3-4 Microphone assignment in Sources
