Euphonix System 5 User Manual

System 5 Digital Audio Mixing System Operation Manual CM403 Film/Post Module
228
15.7 Machine Control
Film environments often require both operators to share control over the machines. A
single synchronizer (such as a CB RM6 or SoundMaster) can combine the machine
control commands from two consoles.
Figure 15-13 Master and Slave Console Hookup
15.8 Track Arming
Starting in v2.5, System 5 supported track arming to allow the user to track arm up to
48 tracks of a single machine via MIDI or P2. The 48 mix busses are hard-mapped to
the 48 tracks. To support arming over multiple P2 machines (i.e., eight 6-track, six 8-track,
or two 24-track machines), a third-party device that distributes 48 tracks from one P2 port
to multiple P2 ports is required. Contact Euphonix customer support for more information.
15.9 Solo-In-Place
Whenever a channel is in solo, any sources currently assigned to the monitors are tempo-
rarily removed (i.e., externals and returns). The monitors automatically source the direct
outputs from the console busses. When the channel is no longer in solo, the monitors
revert to their setup prior to the solo.
third-party
synchronizer
System Computer
System Computer
Slave
Console
Network
Master
Console
Network
TT002 RS422TT002 RS422
