System 5 Digital Audio Mixing System Operation Manual
27
Chapter 3: Quickstart to Common Tasks
3.1 Connect and Play a CD
eMix Setup
1. Select Drives at the bottom of the eMix screen and choose a drive.
2. Click Projects->New, and name the new Project.
3. Click Titles->New, and name the new Title.
4. Click Save the current title and mix data into the new title to use the current
Title’s settings for the new Title (like Save As); click Reset Console with
Default Title settings to use default Title settings.
Figure 3-1 New Title dialog
Assign Channels to Console
1. Select Channels from the main panel viewer in the console master section.
2. Select Auto then Channel 1.
3. Press Chan Sel keys for two neighboring console Strips.
This assigns Channels 1 and 2 to Strips n and n+1, respectively.
Patch the CD Player
1. Select PatchNet from bottom of the eMix screen and select Console I/O.
2. Select A and B Inputs.
3. Select the blue selection box for the A Input of channels 1 and 2.
The patch points show up in Selected - Destinations.
