System 5 Digital Audio Mixing System Operation Manual CM401T Master Section
73
5.2.4 Quick Access Communications Panels
The Quick Access Panel, located below the CR Level area, provides easy, fast access
to the most commonly used Communications parameters without using the Panel Viewer.
Use the buttons above the panel to display Quick Access Panels for general Communi-
cations, Talkback, Listen, and Slate/Osc (Figure 5-8).
Figure 5-8 Quick Access Communication Panels
Mix 1
Tbk Ltch
Tbk>MonD
Tbk>MonC
Tbk>MonB
Tbk>MonA
1>Lsn
All>Lsn
Tbk>MonB
Tbk>MonA
Tbk>Mons
Lsn>Ltch
4>Lsn
3>Lsn
2>Lsn
1>Lsn
Slt>Grp
Slt>Mix
Osc>Grp
Osc>Mix
Osc>Aux
ON
ON
ON
ON
