Euphonix System 5 User Manual

System 5 Digital Audio Mixing System Operation Manual Channels and Strips
98
Multiple Assignments: Channel Assign Panel
The Channel Assign Panel is most commonly used to assign channels to multiple
Strips but can also be used for a single assignment.
1. Press the Main Panel key in the center section.
2. Press the Channels key to display the Channel Assign Panel.
Use the Page keys to display additional channels.
Figure 8-3 Channel Assign Panel
3. In the Channel Assign Panel Viewer, press the key beside the channel you
wish to assign.
4. Activate the Main or Swap channel on the Strip you wish to assign the selected
channel and press its Chan Select key.
Main
Panel
1:C1
Info
Channel Assign
2:C2
3:C3
4:C4
5:C5
6:C6
7:C7
8:C8
9:C9
10:C10
11:C11
12:C12
Name Auto
13:C13
14:C14
15:C15
16:C16
17:C17
18:C18
19:C19
20:C20
21:C21
22:C22
23:C23
24:C24
Pg01
Setup
►◄
