System 5 Digital Audio Mixing System Operation Manual Channels and Strips
103
Spill Select
Spill Select allows Control Groups and Multi Format Masters to spill their slaves to a
defined area (see Spill Area on page 139 to learn how to spill the channels).
To specify a spill area:
1. From the Main Panel, press the Strips key.
2. In the Strip Config Panel Viewer, press the Spill Select key so it lights.
3. Press the Wave key for each strip that is to be part of the spill area.
Fader Unity
Fader Unity allows any fader(s) to be automatically set to unity gain (0 dB).
1. From the Main Panel, press the Strips key.
2. In the Strip Config Panel Viewer, press the Fader Unity key so it lights.
3. Press the Chan Select key for each channel to set unity gain.
The fader moves to 0 dB.
You can also press that channel’s Channel Select key in the center section
Select Panel.
Figure 8-6 Center section Select Panel
4. Deselect the Fader Unity key to turn off the Fader Unity function.
C6
C7
C8
solo
N
ON
solo
ON
solo
ON
Channel
Select key
C5
Strip Zone Select
Strip Zone Select allows two separate Strip Zones on the control surface, simulating a
dual-operator console. Strips selected in Strip Zone Select will be isolated from the
All mode and Spill function operations of the rest of the non-selected strips. A separate
All mode and Spill function can work only on the strips selected in Spill Zone Select.
To create a Strip Zone:
1. From the Main Panel, press the Strips key.
2. Press the Strip Zone Select key on the Strips Panel Viewer.
3. Press the Wave key for each strip that is to be part of the Strip Zone.
The Wave key illuminates.
