System 5 Digital Audio Mixing System Operation Manual eMix Application
50
4.2.6 Monitor Patching
The monitor outputs are automatically routed to the analog patch unit supplied with
System 5 and are ready to be normalled to the speaker inputs. The monitor feeds are
also available within PatchNet for routing to other destinations, if necessary.
Click on the Console I/O category and the Monitor Busses sub-category. This window
shows all 22 monitor feeds:
The Cascade inputs allow for direct bus injection prior to the insert point into all mon-
itor signal paths.
4.2.7 Solo Bus and Utility Patching
The Solo Busses sub-category in Console I/O allows custom patching into the stereo
Solo Bus.
The Utility Sources sub-category includes the Oscillator output. The Utility Destina-
tions sub-category includes the Slate In which must be patched to the Talkback mic
feed from the Monitor Interface.
4.2.8 Talkback Signal Patching
The talkback mics are wired to the MC524 Monitor Controller. They are amplified to
produce a single talkback signal. This analog signal must be fed into the system through
an Analog to MADI converter. See Figure 1-1 on page 22.
To send talkback to the busses, this signal must be patched to the Slate Input (in the
Utility Destinations subcategory of the Console I/O category). Note which analog-to-
MADI converter input the talkback signal has been patched to and connect that channel
to the Slate Input.
Monitor Busses Format
1–8 Control Room L, C, R, Sl, Sr, Bm, X, Y
9–16 Mon A L, C, R, Sl, Sr, Bm, X, Y
17–18 Mon B L, R
19–20 Mon C L, R
21–22 Mon D L, R
