System 5 Digital Audio Mixing System Operation Manual GPI/O Event System
175
13.9.7 Audio Follow Video
In this example, there are four cameras each with a microphone configured with a video
switcher, TT002 GP inputs, and System 5 console (Figure 13-3).
Figure 13-3 Audio Follow video configuration
Camera Inputs
Tally Inputs 1 - 4 to TT002 GPIO connector in System PC
1 2 3 4
1 2 3 4
