110 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 14 Data Logger and Transmission of Data
The following data columns can be transmitted:
Online Transmission of Data
Columns will be created for all quantities that appear during the measurement. The co-
lumns Q_POS and Q_NEG will remain empty if the totalizers are deactivated.
As the totalizers can not be activated for the physical quantity flow velocity, these co-
lumns will not be created.
Offline Transmission of Data
During the offline output, columns will only be created if at least one measured value is
stored in the data set. The columns Q_POS and Q_NEG will not be created if the totali-
zers are deactivated.
Tab. 14.3: Columns of data
column title column format contents
\*MEASURE ###000000.00 physical quantity selected
in Output Options
Q_POS +00000000.00 totalizer value for the positive flow direction
Q_NEG -00000000.00 totalizer value for the negative flow direction
FQ_POS value of the totalizer for the positive flow direction (if the heat
flow has been selected as the physical quantity)
FQ_NEG the value of the totalizer for the negative flow direction (if the
heat flow has been selected as the physical quantity)
T1 ###000.0 temperature T1 (= supply temperature if the heat flow has
been selected as the physical quantity)
T2 ###000.0 temperature T2 (= return temperature if the heat flow has
been selected as the physical quantity)
... designation for other inputs
SSPEED sound speed of the medium
AMP signal amplitude
