7 Installation of FLUXUS G608 FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 45
7.4 Power Supply
The transmitter can be operated with
the battery (see section 7.4.1) or
the power cable and the power adapter (see section 7.4.2).
7.4.1 Power Supply with the Battery
The transmitter has a Li-Ion battery and can be operated independently of the power ca-
ble. When delivered, the battery is charged approx. 30 %. The battery does not need to
be fully charged before it is used for the first time.
Fig. 7.7: Connection of the transducers
Attention! Observe the Safety Instructions for the Use in Explosive Atmo-
sphere (see document SIFLUXUS_608).
Fig. 7.8: Connections of the transmitter FLUXUS G608
A
A
a
b
power supply unit/
battery charging unit
CH A
COMM
OutputInput
DC-IN
CH B
