7 Installation of FLUXUS G608 FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 53
7.7 Connection of the Serial Interface
• Connect the RS232 cable to the transmitter (see Fig. 7.13) and to the serial interface of
the PC. If the RS232 cable can not be connected to the PC, use the RS232/USB
adapter.
The RS232 adapter, the RS232 cable and the RS232/USB adapter are part of the serial
data kit (optional).
Attention! Observe the Safety Instructions for the Use in Explosive Atmo-
sphere (see document SIFLUXUS_608).
Fig. 7.13: Connections of the transmitter FLUXUS G608
CH A
COMM
OutputInput
DC-IN
CH B
serial interface
