142 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 20 Inputs
20 Inputs
External transducers can be connected to the inputs (optional) to measure the following
physical quantities:
temperature
•density
pressure
kinematic viscosity
dynamic viscosity
The values of the current, voltage, and temperature inputs can be used by all measuring
channels.
An input must be assigned to a measuring channel (see section 20.1 and 20.3) and acti-
vated (see section 20.4) before it can be used for the measurement and for the storing of
measured values.
Depending on the configuration of the transmitter, one or several of the following list
items will be displayed:
20.1 Assigning the Temperature Inputs to the Measuring Channels
20.1.1 Assignment of the Temperature Inputs
Note! If a new input module has been installed, the transmitter must be re-
started (RESET or off/on) in order for the new inputs to be identified.
Select Special Funct.\SYSTEM settings\Proc.
inputs.
Tab. 20.1: List items for Proc. inputs
list item function
Link temperature assigning of the temperature inputs to the measuring channels
Link other inp. assigning of other inputs to the measuring channels
PT100/PT1000 selection of a temperature probe
...go back return to the precedent menu item
Select Special Funct.\SYSTEM settings\ Proc.
inputs. Press ENTER.
Select the list item Link temperature.
SYSTEM settings
Proc. inputs
SYSTEM settings
Proc. inputs
Proc. inputs
Link temperature
