4 Transmitter FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 19
4.2 Status Indication
4.3 Serial Number
The type and the serial number are shown on the nameplate of the transmitter. When
contacting FLEXIM, always have both numbers and the number of the firmware version
at hand (see section 17.6).
Tab. 4.1: LED "SIGNAL"
LED off transmitter offline
LED lights green signal quality of the measuring channel sufficient for a measurement
LED lights red signal quality of the measuring channel not sufficient for a measurement
Tab. 4.2: LED "BATTERY"
LED flashes green battery is being charged
LED lights green battery is charged
LED off charge state of the battery > 10 %
LED flashes red charge state of the battery < 10 %
Note! If the LED "BATTERY" flashes red/green, the power supply has an
internal error. Contact FLEXIM for more information.
