20 Inputs FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 145
20.4.2 Activation of Other Inputs
Inputs must be activated if the measured values are to be displayed, stored and/or trans-
mitted together with the other measured values.
20.5 Temperature Correction
A temperature correction value (offset) can be set for each temperature input. If a correc-
tion value has been defined, it will be added automatically to the measured temperature.
This function is useful if e.g.:
• the characteristic curves of the two temperature probes differ considerably from each
other.
• a known and constant temperature gradient exists between the measured temperature
and the actual temperature.
20.5.1 Activation/Deactivation of the Temperature Correction
The temperature correction can be activated/deactivated in program branch Special
Funct.\SYSTEM settings\Dialogs/Menus.
Attention! Observe the correct polarity to avoid damaging the current source. A
permanent short circuit can lead to the destruction of the current in-
put.
In the program branch Output Options, select the
channel for which an input is to be activated.
The inputs assigned to the channel will be displayed one af-
ter another. Select
yes
for the inputs that are to be activated.
Note! The total number of measured values that can be stored will be re-
duced if an input is activated.
Select on to activate the temperature correction, off to
deactivate it.
Note! If off is selected, the temperature correction will be deactivated for
all inputs. However, the entered correction values for each tempera-
ture input will be stored and displayed again when the temperature
correction is activated again.
