146 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 20 Inputs
20.5.2 Input of the Temperature Correction
During the flow transducer positioning, the correction values will be requested for each
input which has been activated and where the temperature can be measured.
Enter the offset for the temperature input.
Press ENTER.
Note! Only measured temperatures can be corrected.
In order to adjust the zero point, the same reference temperature is
measured with the two temperature probes. The difference between
the two measured temperatures is entered as the offset for one of
the temperature inputs. The difference can also be distributed be-
tween the offsets of the two channels.
The display of the temperature difference T1-T2 does not indicate if
one or both temperatures are constant or if the values have been
corrected.
During the measurement, a corrected temperature value is
marked by cor.
