FLUXUS G60x 4 Transmitter
4 Transmitter
4 Transmitter
4.1 Design
Fig. 4.1: Command panel
A handle is mounted to the back side of the transmitter (see Fig. 4.2). It can also be used
as support. The aperture in the support plate is used to fix the transmitter to a pipe (see
section 6.2.3).
Fig. 4.2: Back side
3
C
B R K
8
FLUXUS G60X
CHANNEL A
CHANNELB
2x 16-digit LCD display,
backlit
state indicator
"SIGNAL"
keyboard
state indicator
"BATTERY"
handle/support
opening in the
support plate
for the button
