86 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 12 Displaying the Measured Values
All Channels
The measured values of all channels (measuring and calculation channels) are dis-
played. The next active channel is displayed after min. 1.5 s.
Only Calculation Channels
Only the measured values of the calculation channels are displayed. The next active cal-
culation channel is displayed after min. 1.5 s.
This mode can only be activated if at least 2 calculation channels are active.
12.2.2 HumanMux Mode
In the HumanMux mode, the measured values of one channel are displayed. The mea-
surement on the other channels is continued, but not displayed.
Press key to display the next activated channel. The measured values of the selected
channel will be displayed as configured in the program branch Output Options (see
section 12.1).
12.3 Adjustment of the Display
During the measurement, the display can be adapted as to display two measured values
simultaneously (one in each line of the display). This does not affect totalizing, storing of
measured values, measured value transmission, etc.
The following information can be displayed in the upper line:
• designation of the physical quantity
• totalizer values, if activated
• temperatures assigned to the channel and their difference if the temperature is mea-
sured
• date and time at which the data logger will be full
• measuring mode
• transducer distance
• alarm state indication if it is activated (see section 21.7.5) and if alarm outputs are acti-
vated (see section 21.6).
• charge state of the battery
The following information can be displayed in the lower line:
• flow velocity
• sound speed
• mass flow rate
• volumetric flow rate
Press key during the measurement to change the display in the upper line, press key
to change the display in the lower line.
The selected channel is displayed left in the upper line.
