130 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 18 SuperUser Mode
18.3 Defining the Flow Parameters
In the SuperUser mode, it is possible to define some flow parameters (profile bounds,
correction of the flow velocity) for the specific application or measuring point.
18.3.1 Profile Bounds
If Special Version has been selected, the transducer
parameters must be entered.
The transducer parameters must be provided by the trans-
ducer manufacturer. Press ENTER after each input.
Select Special Funct.\SYSTEM settings\Measur-
ing\Calibration. Press ENTER.
Select the measuring channel for which the flow parame-
ters are to be defined. Press ENTER.
Select user if the profile bounds are to be defined. If
factory is selected, the default profile bounds will be
used and the menu item Calibration will be displayed
(see section 18.3.2).
Press ENTER.
Enter the max. Reynolds number at which the flow is lami-
nar. The entered number will be rounded to the hundreds.
Enter 0 (zero) to use the default value.
range: 0...25 500
default: 1 000
Press ENTER.
Enter the min. Reynolds number at which the flow is turbu-
lent. The entered number will be rounded to the hundreds.
Enter 0 (zero) to use the default value.
range: 0...25 500
default: 3 000
Press ENTER.
Calibrat. data ↕
for Channel A:
A:Profile bounds
factory >USER<
To Next Page
