152 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 21 Outputs
Test of the Binary Outputs
21.2 Error Value Delay
The error value delay is the time interval after which the error value will be transmitted to
the output in case no valid measured values are available. The error value delay can be
entered in the program branch Output Options if this menu item has been previously
activated in the program branch Special Funct.. If the error value delay is not en-
tered, the damping factor will be used.
If the multimeter displays the entered value, the output
functions correctly.
Select yes to repeat the test, no to return to SYSTEM
settings. Press ENTER.
Select Reed-Relay OFF or Open collect OFF in the
scroll list Output Test to test the de-energized state of
the output. Press ENTER. Measure the resistance at the
output. The value has to be high ohmic.
Select yes. Press ENTER.
Select Reed-Relay ON or Open collect. ON in the
scroll list Output Test to test the energized state of the
output. Press ENTER. Measure the resistance at the out-
put. The value has to be low ohmic.
Select yes to repeat the test, no to return to SYSTEM
settings. Press ENTER.
Select Special Funct.\SYSTEM settings\Dia-
logs/Menus\Error-val. delay.
Select Damping if the damping factor is to be used as the
error value delay. Select Edit to activate the menu item
Error-val. delay in the program branch Output Options.
From now on, the error value delay can be entered in the
program branch Output Options.
I1= 4.0 mA
Again? no >YES<
B1:Output Test ↕
Reed-Relay OFF
B1:Output Test ↕
Reed-Relay ON
Error-val. delay
>DAMPING< edit
